| Parameter | pH |
|---|---|
| Measurement Principle | Glass electrode |
| Measurement Range | pH0 ~ pH14 |
| Measurement Resolution | 0.01 |
| Measurement Interval | ＞1s |
| Ambient Pressure | max. 2 bar at 20℃ |
| Probe conductivity | ＞150 us/cm |
| Temperature Range | -5℃ to 70℃ |
| Parameter | Turbidity |
|---|---|
| Principle | 90˚ scattered light |
| Range | 0~50/100/1000/4000 FUN |
| Accuracy | 3% FS |
| Interval | ＞1s |
| Detection Limit | 0.1 FNU |
| Light Source | 860 nm |
| Parameter | Chlorine |
|---|---|
| Principle | Membrane covered, amperometric working potentiostatic 3-electrode system with integrated electronic |
| Measurand | free chlorine |
| Operating temperature | ＞5℃ to ＜45℃ |
| max. operating pressure | 0,5 bar, no pressure surges and/or vibrations |
| pH-range | pH6 - pH8, reduced pH-value-dependence |
| Parameter | Oil |
|---|---|
| Principle | Fluorescence measurement Evaluation (300-400 nm) |
| Measurand | Refined oil in water, BTEX, PAH |
| Range | 0-30/100/300 ppm |
| Parameter | Dissolved oxygen in water |
|---|---|
| Principle | Optical (Luminescence) or Galvanic |
| Range | 0-20 mg/L (0-200% Sat) |
| Accuracy | ＞0.1% |
